Quick Reference to AMOS Functions

Shortcut Keys for AMOS Functions:

F1 = Search Content Directory
F2 = “Select one object at a time” button
F3 = “Draw Observed Variable” button
F4 = “Draw Unobserved Variable” button
F5 = “Draw Path (single head)” button
F6 = “Draw Covariance” button
F7 = “Zoom in” button
F8 = “Zoom out” button
F9 = “Zoom page” button
F10 = “View Output” button
F11 = “Full Screen viewing” button
F12 = “Examine diagram with Loupe” button—magnifying glass
Ctrl + B = Bayesian Analysis function
Ctrl + C = Copy model to clipboard
Ctrl + D = Select Data file function
Ctrl + E = View Interface Properties
Ctrl + F = Fit the model to the page
Ctrl + G = Drag properties function
Ctrl + H = Use the touch up function
Ctrl + M = Move one object at a time
Ctrl + O = Object Properties function
Ctrl + P = Print the model
Ctrl + R = View Analysis Properties
Ctrl + S = Save function
Ctrl +V = Paste model from clipboard
Ctrl +Y = Redo function
Ctrl + Z = Undo function
Ctrl + F9 = Calculate Estimates function
Alt + F8 = Plugins Menu

Ctrl + F9 = Calculate Estimates function

Alt + F8 = Plugins Menu

*Note: These are the shortcut keys as of AMOS 26

Source: Thakkar, J.J. (2020). “Procedural Steps in Structural Equation Modelling”. In: Structural Equation Modelling. Studies in Systems, Decision and Control, vol 285. Springer, Singapore.
